| Feature | Details |
|---|---|
| Interface |
??? 1?? 10/100Mbps LAN Port ??? 1?? 10/100Mbps LAN/WAN Port ??? 1?? Nano SIM Card Slot ??? 2?? External SMA-F Antenna Interface |
| Button | Reset/WPS Button |
| External Power Supply (EU) | 9V/0.85A |
| Dimensions (W ?? D ?? H) | 6.85 ?? 5.12 ?? 2.36 in (174 ?? 130 ?? 60 mm) |
| Antenna |
??? 2?? Internal 4G/3G Antennas ??? 2?? Internal Wi-Fi Antennas |
| Wireless Standards | IEEE 802.11b/g/n |
| Frequency | 2.4 GHz |
| Signal Rate | 300 Mbps |
| Reception Sensitivity |
??? 11g 54M: -74dBm ??? 11n HT20: -73dBm ??? 11n HT40: -70dBm |
| Transmit Power | < 20 dBm (2.4 GHz) |
| Wireless Functions | Enable/Disable Wireless Radio, Wireless Schedule, WMM, Wireless Statistics |
| WAN Failover | Yes |
| Wireless Security | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryptions |
| Network Type |
??? 4G: FDD-LTE: B1/B3/B5/B7/B8/B20/B28 (2100/1800/850/2600/900/800/750 MHz) ??? TDD-LTE: B38/B40/B41 (2600/2300/2500 MHz) ??? 3G: DC-HSPA+/HSPA/UMTS: B1/B5/B8 (2100/850/900 MHz) |
| Security | IPv4 SPI Firewall, IP and MAC Address Binding |
| Operating Modes | 3G/4G Router, Wireless Router |
| WAN Type | Dynamic IP, Static IP, PPPoE, PPTP (Dual Access), L2TP (Dual Access) |
| Management | Local Management, Remote Management |
| DHCP | Server, DHCP Client List, Address Reservation |
| Port Forwarding | ALG, Virtual Server, Port Triggering, UPnP, DMZ |
| Dynamic DNS | TP-Link, DynDNS, NO-IP |
| Protocols | IPv4, IPv6 |
| Guest Network | 2.4 GHz Guest Network |
| Administration | Upgrade Firmware, Factory Default, System Log, Diagnostic Tools |
| Certification | CE, RoHS |
| Package Contents |
??? 300 Mbps Wireless N 4G LTE TL-MR105 ??? 1.5m Power Adapter ??? RJ45 Ethernet Cable ??? Quick Installation Guide |
| Requirements |
??? Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser ??? Nano SIM Card |
| Environment |
??? Operating Temperature: 0???~40??? (32??? ~104???) ??? Operating Humidity: 10%~90% non-condensing ??? Storage Humidity: 5%~90% non-condensing |
| Feature | Details |
|---|---|
| Interface |
??? 1?? 10/100Mbps LAN Port ??? 1?? 10/100Mbps LAN/WAN Port ??? 1?? Nano SIM Card Slot ??? 2?? External SMA-F Antenna Interface |
| Button | Reset/WPS Button |
| External Power Supply (EU) | 9V/0.85A |
| Dimensions (W ?? D ?? H) | 6.85 ?? 5.12 ?? 2.36 in (174 ?? 130 ?? 60 mm) |
| Antenna |
??? 2?? Internal 4G/3G Antennas ??? 2?? Internal Wi-Fi Antennas |
| Wireless Standards | IEEE 802.11b/g/n |
| Frequency | 2.4 GHz |
| Signal Rate | 300 Mbps |
| Reception Sensitivity |
??? 11g 54M: -74dBm ??? 11n HT20: -73dBm ??? 11n HT40: -70dBm |
| Transmit Power | < 20 dBm (2.4 GHz) |
| Wireless Functions | Enable/Disable Wireless Radio, Wireless Schedule, WMM, Wireless Statistics |
| WAN Failover | Yes |
| Wireless Security | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryptions |
| Network Type |
??? 4G: FDD-LTE: B1/B3/B5/B7/B8/B20/B28 (2100/1800/850/2600/900/800/750 MHz) ??? TDD-LTE: B38/B40/B41 (2600/2300/2500 MHz) ??? 3G: DC-HSPA+/HSPA/UMTS: B1/B5/B8 (2100/850/900 MHz) |
| Security | IPv4 SPI Firewall, IP and MAC Address Binding |
| Operating Modes | 3G/4G Router, Wireless Router |
| WAN Type | Dynamic IP, Static IP, PPPoE, PPTP (Dual Access), L2TP (Dual Access) |
| Management | Local Management, Remote Management |
| DHCP | Server, DHCP Client List, Address Reservation |
| Port Forwarding | ALG, Virtual Server, Port Triggering, UPnP, DMZ |
| Dynamic DNS | TP-Link, DynDNS, NO-IP |
| Protocols | IPv4, IPv6 |
| Guest Network | 2.4 GHz Guest Network |
| Administration | Upgrade Firmware, Factory Default, System Log, Diagnostic Tools |
| Certification | CE, RoHS |
| Package Contents |
??? 300 Mbps Wireless N 4G LTE TL-MR105 ??? 1.5m Power Adapter ??? RJ45 Ethernet Cable ??? Quick Installation Guide |
| Requirements |
??? Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser ??? Nano SIM Card |
| Environment |
??? Operating Temperature: 0???~40??? (32??? ~104???) ??? Operating Humidity: 10%~90% non-condensing ??? Storage Humidity: 5%~90% non-condensing |
