| TS-231P3-4G (Legacy) Specifications | |
| CPU | AnnapurnaLabs, an Amazon company Alpine AL314, 4-core, 1.7GHz |
| CPU Architecture | 32-bit ARM |
| Floating Point Unit | Yes |
| Encryption Engine | Yes |
| System Memory | 4GB SODIMM DDR3 |
| Maximum Memory | 8GB DDR3 |
| Memory Slot | 1 x SODIMM DDR3 |
| Flash Memory | 512 MB (Dual boot OS protection) |
| Drive Bay | 2 x 3.5-inch SATA 6Gb/s, 3Gb/s |
| Drive Compatibility | 3.5-inch SATA hard disk drives, 2.5-inch SATA hard disk drives, 2.5-inch SATA solid-state drives |
| Hot-swappable | Yes |
| SSD Cache Acceleration Support | Yes |
| Gigabit Ethernet Port (RJ45) | 1 |
| 2.5 Gigabit Ethernet Port (2.5G/1G/100M) | 1 (2.5G/1G/100M) |
| Wake on LAN (WOL) | Yes (Only the 1GbE port) |
| Jumbo Frame | Yes |
| USB 3.2 Gen 1 port | 3 |
| Form Factor | Tower |
| LED Indicators | Power, Status, LAN, USB, HDD1-2 |
| Buttons | Power, Reset, USB Auto Copy |
| Dimensions (HxWxD) | 165 ?? 102 ?? 220.6 mm |
| Weight (Net) | 1.46 kg |
| Weight (Gross) | 2.46 kg |
| Operating Temperature | 0 - 40 ??C (32??F - 104??F) |
| Storage Temperature | -20 - 70??C (-4??F - 158??F) |
| Relative Humidity | 5-95% RH non-condensing, wet bulb: 27??C (80.6??F) |
| Power Supply Unit | 60W/65W adapter (12VDC), 100-240VAC |
| Power Consumption: HDD Sleep Mode | 8.46 W |
| Power Consumption: Operating Mode, Typical | 15.6 W (Tested with drives fully populated) |
| Fan | 1 x 70mm, 12VDC |
| System Warning | Buzzer |
| Kensington Security Slot | Yes |
| Standard Warranty | 2 years |
| Max. Number of Concurrent Connections (CIFS) - with Max. Memory | 400 |
