| Zones | 64 (8 On-board zones, max 8 wired PIRCAM) |
| Area | 32 |
| User |
Installer: 1 Administrator: 1 Operator: 62 |
| SMS notification | Support (with GPRS/3G/4G module) |
| Onboard video clips | 4 |
| ARC protocol |
ISAPI: Supports iVMS-4200 client software and web client Cloud P2P: Supports cloud P2P privacy protocol DC-09: ARC accessible (ADM-CID/SIA-DCS) CSV-IP: Supports CSV-IP ISUP: Supports ISUP 5.0 |
| Programming tools | Web/iVMS-4200/Hik-Partner Pro/Keypad |
| Firmware upgrade | Web/iVMS-4200/Hik-Partner Pro |
| End of Line Resistance | Support 1K, 2.2K, 4.7K, 5.6K, 6.8K, 8.2K |
| Alarm input | 64 (Including 8 on-board zones) |
| Alarm output | 64 (Including 2 on-board relay outputs and 2 on-board I/O outputs) |
| Power Output |
1. Bell: maximum 12V 1.2A 2. AUX: maximum 12V 1.5A |
| 3/4G on board | Optional |
| GPRS on board | Optional |
| Wi-Fi | 802.11b/g/n (2.4GHz) |
| Bus | 1 Speed-X bus |
| Sounder output | 1 Wired on-board sounder output |
| Tamper-Proof |
1 switch to detect removal from mounting 1 switch to detect front cover open |
| Network interface | 1 RJ45 10M/100M Ethernet interface |
| Power interface | 100 to 240 VAC (on-board power transformer) |
| Power Consumption |
1. 220V power supply ??? With an alarm: 2A, 32W ??? Without an alarm: 250mA, 4W 2. 13.5V battery supply ??? With an alarm: 1.7A, 25W ??? Without an alarm: 200mA, 2.7W |
| Battery type | Lead acid battery (12V 7Ah, battery is not included by default) |
| Battery life span | Up to 36hrs |
| Display |
4 On-board LEDs: ??? 1 AC power LED indicator (Green) ??? 1 System status LED indicator (Green/Red) ??? 1 PSTN status LED indicator (Green/Red) ??? 1 Mobile communication status LED indicator (Green/Red) |
| Operation temperature | -10??C to 40??C |
| Operation humidity | 10% to 90% |
| Shell material | Plastic |
| Color | White |
| Dimension (WxHxD) | 261 mm ?? 199 mm ?? 86.4 mm |
| Weight | 997 g |
| Device management |
Tag: 64 Keyfob: 64 Keypad: 8 Wireless sounder: 16 |
| Zones | 64 (8 On-board zones, max 8 wired PIRCAM) |
| Area | 32 |
| User |
Installer: 1 Administrator: 1 Operator: 62 |
| SMS notification | Support (with GPRS/3G/4G module) |
| Onboard video clips | 4 |
| ARC protocol |
ISAPI: Supports iVMS-4200 client software and web client Cloud P2P: Supports cloud P2P privacy protocol DC-09: ARC accessible (ADM-CID/SIA-DCS) CSV-IP: Supports CSV-IP ISUP: Supports ISUP 5.0 |
| Programming tools | Web/iVMS-4200/Hik-Partner Pro/Keypad |
| Firmware upgrade | Web/iVMS-4200/Hik-Partner Pro |
| End of Line Resistance | Support 1K, 2.2K, 4.7K, 5.6K, 6.8K, 8.2K |
| Alarm input | 64 (Including 8 on-board zones) |
| Alarm output | 64 (Including 2 on-board relay outputs and 2 on-board I/O outputs) |
| Power Output |
1. Bell: maximum 12V 1.2A 2. AUX: maximum 12V 1.5A |
| 3/4G on board | Optional |
| GPRS on board | Optional |
| Wi-Fi | 802.11b/g/n (2.4GHz) |
| Bus | 1 Speed-X bus |
| Sounder output | 1 Wired on-board sounder output |
| Tamper-Proof |
1 switch to detect removal from mounting 1 switch to detect front cover open |
| Network interface | 1 RJ45 10M/100M Ethernet interface |
| Power interface | 100 to 240 VAC (on-board power transformer) |
| Power Consumption |
1. 220V power supply ??? With an alarm: 2A, 32W ??? Without an alarm: 250mA, 4W 2. 13.5V battery supply ??? With an alarm: 1.7A, 25W ??? Without an alarm: 200mA, 2.7W |
| Battery type | Lead acid battery (12V 7Ah, battery is not included by default) |
| Battery life span | Up to 36hrs |
| Display |
4 On-board LEDs: ??? 1 AC power LED indicator (Green) ??? 1 System status LED indicator (Green/Red) ??? 1 PSTN status LED indicator (Green/Red) ??? 1 Mobile communication status LED indicator (Green/Red) |
| Operation temperature | -10??C to 40??C |
| Operation humidity | 10% to 90% |
| Shell material | Plastic |
| Color | White |
| Dimension (WxHxD) | 261 mm ?? 199 mm ?? 86.4 mm |
| Weight | 997 g |
| Device management |
Tag: 64 Keyfob: 64 Keypad: 8 Wireless sounder: 16 |
